RBBAnimation is a subclass of CAKeyframeAnimation that allows you to use blocks to describe your animation instead of having to write out every frame by hand.

It comes out of the box with a replacement for CASpringAnimation, support for custom easing functions such as bouncing as well as hooks to allow you to write your own animations fully from scratch.


RBBCustomAnimation is the most flexible of the RBBAnimation subclasses. To use it, simply create a new animation as you normally would an pass in an RBBAnimationBlock from which you return the desired value for a given point in time.

animation.animationBlock = ^(CGFloat elapsed, CGFloat duration) {
    UIColor *color = [UIColor colorWithHue:elapsed / duration

    return (id)color.CGColor;

That being said, you’ll probably want to use the higher-level RBBTweenAnimation.


RBBTweenAnimation is similar to CABasicAnimation in that it smoothly interpolates between two values. Unlike CABasicAnimation however, it supports a wider variety of easing functions.

Easing functions (or timing functions) are used to describe how fast values change during an animation. Core Animation comes with the CAMediaTimingFunction class, but it’s limited to cubic Bézier curves.

They are also available for RBBTweenAnimation through the RBBCubicBezier helper:

RBBCubicBezier(0.68, -0.55, 0.265, 1.55)
animation.easing = RBBCubicBezier(0.68, -0.55, 0.265, 1.55);
animation.duration = 0.6;

However, RBBTweenAnimation also supports more complex easing functions such as RBBEasingFunctionEaseOutBounce:

animation.easing = RBBEasingFunctionEaseOutBounce;
animation.duration = 0.8;

If you fancy, you can also specify your own easing functions, like this sine wave here, from scratch:

Custom easing function
animation.easing = ^CGFloat (CGFloat fraction) {
    return sin((fraction) * 2 * M_PI);


While Core Animation comes with a CASpringAnimation class to model damped springs, it’s private API and thus (more or less) off-limits, quite a shame since it’s a really gorgeous effect.

I’ve implemented RBBSpringAnimation as a replacement, simply specify the springs mass, damping, stiffness as well as its initial velocity and watch it go:

RBBSpringAnimation *animation = [RBBSpringAnimation animationWithKeyPath:@"position.y"];

animation.velocity = 0;
animation.mass = 1;
animation.damping = 10;
animation.stiffness = 100;

You can find the code on GitHub, it’s MIT licensed and also available through CocoaPods.

I hope RBBAnimation will be useful to you. If you end up using it in one of your apps, I’d love to hear about that.

Posted Oct 31, 2013 in working-on
